Veolia E-Cell MK-3 Mini HT EDI module for pharmaceutical ultrapure water production
Productdetails:
| Plaats van herkomst: | CHINA |
| Merknaam: | VEOLIA |
| Certificering: | CE |
| Modelnummer: | Veolia edi mk-3miniht |
| Document: | FSpwE-CellMK-3MiniHT_EN.pdf |
Betalen & Verzenden Algemene voorwaarden:
| Min. bestelaantal: | 1 pc |
|---|---|
| Prijs: | onderhandelbaar |
| Verpakking Details: | Standaard exportpakking |
| Levertijd: | 1 maand |
| Betalingscondities: | T/t |
| Levering vermogen: | 60000 eenheden per maand |
|
Gedetailleerde informatie |
|||
| MiniHT -stroomsnelheidsbereik: | 0,5-1,6 m3 /u (2.2–7,0 gpm) | Miniht product verzendgewicht: | 57 kg (126 lbs) |
|---|---|---|---|
| Miniht -afmetingen van dit model (breedte x hoogte x diepte): | 30 cm x 61 cm x 29 cm | Miniht -weerstand: | ≥ 10 (farmaceutisch) of ≥ 16 mohm-cm (industrieel |
| Product natrium: | ≤ 3 ppb (industrieel) | Maximale productietemperatuur van het product: | 85ºC (185ºF) |
| Product Maximale inlaatdruk van schapen: | 2.1 bar (30 psi) | producttoepassing: | Farmaceutisch en laboratorium gezuiverd water dat voldoet aan USP en EP |
| Markeren: | Veolia E-Cell MK-3 EDI module,pharmaceutical ultrapure water EDI,mini HT EDI module |
||
Productomschrijving
The Veolia E-Cell MK-3 Mini HT Electrodeionization (EDI) Module is designed for polishing reverse osmosis (RO) permeate to produce ultra-pure water. It delivers high-purity water (up to 10 MΩ·cm resistivity, with ≤5 ppb silica) without chemical regeneration. Ideal for power generation, semiconductors, microelectronics, and pharmaceuticals, this compact module (30x61x28 cm) offers continuous operation, high recovery rates (78-93%), and hot water sanitization capabilities
| Flow Rate Range | 0.5–1.6 m³/h (2.2–7.0 gpm) |
| Shipping Weight | 57 kg (126 lbs) |
| Dimensions | 30 cm x 61 cm x 29 cm |
| Resistivity | ≥ 10 MOhm-cm (Pharmaceutical) or ≥ 16 MOhm-cm (Industrial) |
| Maximum Sanitization Temperature | 85ºC (185ºF) |
- Patented HT-EDI™ technology for reagent-grade water production
- 90% lower energy consumption compared to mixed-bed systems
- Maintenance-free operation with intelligent control system
- Real-time monitoring of conductivity, pH, and pressure drop
- Patented staggered flow channel design prevents scaling
Maintains resistivity above 18.2 MΩ*cm with 22% energy reduction compared to traditional EDI equipment. Achieves recovery rates exceeding 90% even with high-hardness raw water.
- Basic Unit - Standalone purification
- RO-EDI Integrated - Complete purification skid
- GMP Version - With full validation support
- CE, RoHS, CSA and EAC marked
- FDA-compliant materials
- UKCA certified
- Manufactured in ISO 9001 and ISO 14001 facility
- Halal certified by IFANCA®
| Parameter | Value |
|---|---|
| Inlet Pressure | 6.9 bar (100 psi) |
| Max Temperature | 40°C (104°F) |
| Pressure Drop | 1.4-2.8 bar (20-40 psi) |
| Recovery Rate | Up to 93% |
| Conductivity | <117 µS/cm |
| pH Range | 4-11 |
Ideal for water for injection, pharmaceutical purified water, and laboratory purified water systems. Complies with USP, EP, and other pharmacopeia standards.
